There are three types of stone saws commonly used in the stone industry: single-column cantilever stone saws, double-column gantry stone saws, and four-column stone saws.1. Single-column cantilever stone saw
The single-column cantilever stone saws are widely used due to their simple structure and low price.2. Double-column gantry stone saw
The sawing head of the double-column gantry stone saw is mostly fixed on the sliding box, and the box will reciprocate on the beam. When cutting stone, the trolley is fixed and the machine is stable, making it widely used by the plate stone factory and stele stone factory.3. Four-column stone saw
Saws with this structure are usually combined saws, especially large combined saws, because the four columns and other frames formed a very stable structure. Besides, the size of the columns and beams are large, making it possible to cut big blocks.
The cutter shaft adopts a multi support structure instead of cantilever structure and the cutter base has a large size, making the cutter stable and the force uniform, so many cutters can be installed. In this way, the large blocks can be loaded into the machine and can be multi-level cut with high quality and high efficiency, you can also determine different parameters according to different materials and sizes. Adopting frequency conversion equipment, speed and displacement can be well controlled, and the specifications are all displayed as numbers in the computer or on the screen, which allows the cutting process to be completed automatically.
